Product Details
Place of Origin: Hubei, China
Brand Name: OEM
Model Number: See details
Payment & Shipping Terms
Minimum Order Quantity: 500 watts
Price: $0.21-0.28 / watt
Cell Size: |
182mmx182mm, 182mm*182mm |
Type: |
Half Cell |
Panel Dimensions: |
2278 * 1134 * 35mm(89.69*44.65*1.38in) |
Panel Efficiency: |
21.3%, 21.3% |
Application: |
Solar Panel System |
Product Name: |
Sola Panel |
Certificate: |
CE TUV |
Warranty: |
25 Years, 30 Year |
Solar Cell: |
144 Cells |
OEM Order: |
Acceptable |
Color: |
Customized Color |
Packing: |
Wooden Case |
Cell Size: |
182mmx182mm, 182mm*182mm |
Type: |
Half Cell |
Panel Dimensions: |
2278 * 1134 * 35mm(89.69*44.65*1.38in) |
Panel Efficiency: |
21.3%, 21.3% |
Application: |
Solar Panel System |
Product Name: |
Sola Panel |
Certificate: |
CE TUV |
Warranty: |
25 Years, 30 Year |
Solar Cell: |
144 Cells |
OEM Order: |
Acceptable |
Color: |
Customized Color |
Packing: |
Wooden Case |
Electrical Characteristic | ||||||||||||||||||
Rated output (Pmp/Wp) | 520W | 525W | 530W | 535W | 540W | 545W | 550W | 555W | 560W | |||||||||
Open Circuit Voltage(Voc) | 48.9 | 49.05 | 49.20 | 49.35 | 49.50 | 49.65 | 49.90 | 50.05 | 50.20 | |||||||||
Short Circuit Current(Isc) | 13.57 | 13.65 | 13.71 | 13.78 | 13.85 | 13.92 | 14.00 | 14.07 | 14.14 | |||||||||
Maximum Power Voltage(Vmpp) | 41.05 | 41.20 | 41.35 | 41.50 | 41.65 | 41.80 | 41.96 | 42.12 | 42.28 | |||||||||
Maximum Power Current(Impp) | 12.67 | 12.79 | 12.82 | 12.90 | 12.97 | 13.04 | 13.11 | 13.18 | 13.25 | |||||||||
Module efficiency(%) | 20.3% | 20.5% | 20.7% | 20.9% | 21.1% | 21.3% | 21.5% | 21.7% | 21.9% | |||||||||
Standard Test Condition(STC) | Irradiance 1000w/m2, Cell Temperature 25 Centigrade, Air Mass 1.5 | |||||||||||||||||
Mechanical Characteristic | ||||||||||||||||||
No.of Cells | 144(6x24) | |||||||||||||||||
Weight | 32.3kg | |||||||||||||||||
Dimension | 2256x1133x35mm | |||||||||||||||||
Junction Box | IP68,three diodes | |||||||||||||||||
Output Cables | 4mm2,positive 400mm /negative 200mm ,length can be customized | |||||||||||||||||
Glass | Dual glass,3.2mm coated tempered glass | |||||||||||||||||
Frame | Anodized aluminum alloy frame | |||||||||||||||||
